The Dell 1.6TB SAS 12G Mixed-Use SSD featuring the Toshiba PX04SMB160 (Dell P/N 77K16 / 077K16, Toshiba model SDFAR01DAA01) is an enterprise-class solid state drive engineered for high-performance and reliability in Dell PowerEdge server environments. Built on eMLC NAND flash, this drive delivers excellent endurance and consistent performance for mixed read/write workloads.
Designed for mission-critical applications, this hot-swap 2.5-inch SAS SSD is ideal for virtualization, databases, transactional systems, and cloud infrastructure requiring sustained I/O and data integrity.
Key Specifications
-
Capacity: 1.6TB (1600GB)
-
Dell Part Numbers: 77K16, 077K16
-
Manufacturer Model: Toshiba PX04SMB160 / SDFAR01DAA01
-
Interface: SAS 12Gb/s (SAS 3.0)
-
Form Factor: 2.5" Small Form Factor (SFF)
-
Flash Type: eMLC (Enterprise Multi-Level Cell) NAND
-
Drive Type: Enterprise SSD, hot-swap capable
Performance
-
Sequential Read: Up to 1,900 MiB/s
-
Sequential Write: Up to 850 MiB/s
-
Random Read (4KB): Up to 270,000 IOPS
-
Random Write (4KB): Up to 90,000 IOPS
Endurance & Reliability
-
Workload Type: Mixed-Use / Write-Intensive
-
Endurance Rating: Up to 10 DWPD (100% random workload)
-
Power-Loss Protection (PLP): Yes
-
End-to-End Data Protection: T10 DIF support
-
Pin-3 Power Disable: Supported
Compatibility
-
Designed specifically for Dell PowerEdge servers, including but not limited to:
R630, R730, T630, R640, R740, and related enterprise platforms -
Not compatible with consumer desktops or laptops
Key Benefits
-
High endurance for mixed and write-intensive workloads
-
Reliable SAS 12Gb/s performance for enterprise storage arrays
-
Advanced data protection for mission-critical environments
-
Hot-swappable design for minimal downtime
The Dell Toshiba PX04SMB160 1.6TB SAS SSD is a proven enterprise storage solution that delivers durability, speed, and reliability for demanding data center and server applications, making it an excellent choice for production workloads and long-term deployments.
